Products Description


Working Voltage DC 9V - 95V
Internal Battery Capacity 180mAh 3.7V
Working Temperature -20 - 75
Storage Temperature -30 - 80
Working Humidity 10%-85% RH
Working Current 12V/45mA
Standby Current 12V/15mA
GPS Module AT6558R
Communication Module brand/Chip Module EC200SCN
Network 4G
Tracking Sensitivity -162dbm
Capture Sensitivity -148dbm
Location Accuracy 10m
Cold Start Average 32 seconds
Hot Start Average 1 seconds
Weight 75g
Dimension 99mm * 54mm * 16.5mm


1. GPS+AGPS+LBS Multi-Mode Positioning
2. ACC Detection
3. Vibration Alert
4. Burglar Alert
5. Overspeed Alert
6. Low Battery Alert
7. SOS Alert
8. GEO Fence
9. Historical Route
10. External MIC
11. Fuel Sensor

12. Cut off/Resume oil(optional, relay required)

Tracking platform
platform: http://www.18gps.net
Company Profile



1. who are we?
We are based in Guangdong, China, start from 2005,sell to North America(50.00%),Western Europe(20.00%),South
America(20.00%),Eastern Europe(10.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment.
3.what can you buy from us?
gps tracker
4. why should you buy from us not from other suppliers?
- self-owned R& D team for hardware and software
- self-owned antenna GPS factory ( sintering- debugging
- mass production) -self-owned assembly factory
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,Express Delivery;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,PayPal,Western Union;
Language Spoken:English,Chinese.
